The uASIC product family introduces **AM1U1412**, joining the mass production lineup. **AM1U1412** bridges the digital and analog worlds, expanding the horizons of uASIC.

Compact in size at just 1.6×1.6×0.42mm, it comes in a 12-pin TQFN package, providing 10 customizing IO pins. It combines wide supply flexibility (1.71-5.5V) with ultra-low current.

The device can deliver up to 16 LUTs, alongside 8 D-flip-flops, 8 latches, and a 16-bit shift register for sequential design.

Timing resources include three 8-bit timers, one 16-bit timer, and programmable delay cell, giving designers precise control over event scheduling and signal alignment.


**Key Features**:

**Energy Efficiency**

- Chip quiescent current: <0.6 µA
- Analog comparators (Low Power mode): 1.2 µA
- Oscillator (25 kHz mode): <0.37 µA

**Flexibility**

- Configurable digital and analog resources
- Wide supply voltage range: 1.71–5.5 V
- 10 fully customizable IO pins
- Asynchronous design supporting frequencies up to ~100 MHz

**Applications**

- Power sequencing and management
- Watchdog timers
- Custom digital signal generators
- PWM generation and motor control
- Mixed-signal data processing (digital and analog)
- Voltage monitoring and supervisory circuits
- LED drivers and lighting control
- Switch debouncing
- Data conversion and signal shaping
- Event counters and frequency dividers
- One-wire interfaces
- Sensor interfacing and signal conditioning
- Low-power wake-up and monitoring circuits
- Portable and battery-powered devices

From simple controllers to sophisticated mixed-signal systems, AM1U1412 offers virtually endless possibilities, driven by the ingenuity of the designer.

On the analog domain, the device features two highly configurable comparators, each capable of operating in Fast Speed / Low Power mode. For even greater energy efficiency, the comparators also support a Wake&Sleep mode. Reference voltages can be sourced from the internal reference or supplied externally, offering flexible control over switching thresholds.

The integrated voltage reference can be used to set comparator switching levels or provide voltage to external circuits.

A 100 µA current source further extends the chip's ability to interface with the analog world.

The configurable oscillator can operate at either 25kHz or 2MHz, with multiple prescaler stages for flexible frequency division. It can also receive clock pulses from external sources via IO pins, and designers can route two prescaled frequencies to internal macrocells or external circuits.

The oscillator supports both forced and auto power on modes. The auto power on mode enhances the uASIC's energy efficiency.

AM1U1412 supports robust execution, combining standard CRC checks at startup with the team's proprietary CRV method, a continuous monitoring system that ensures functional correctness throughout operation. Together, these mechanisms guarantee dependable performance throughout the chip's operation. Additionally, the chip can be reset on demand, providing an extra layer of operational safety.

AM1U1412 is a truly progressive chip, seamlessly integrating digital and analog signal processing with carefully designed power management and robust reliability.

Designers benefit from [Atlas EDA](https://atlasmagnetics.com/edea) for convenient designing and simulation, along with customer-focused support from our engineering team.

large_1412 final.jpg

medium_1412 final.jpg

small_1412 final.jpg

thumbnail_1412 final.jpg

1412 final.jpg

AM1U1412 goes to Mass Production

Atlas Magnetics is proud to announce that the AM1U1412 µASIC has officially entered mass production - a major milestone in our mission to deliver compact, efficient, and highly reliable solutions, growing the range of mixed-signal products and applications.

Engineered for performance and scalability, the AM1U1412 integrates advanced semiconductor technology with seamless design compatibility. It’s an ideal fit for a wide range of applications, from consumer electronics to industrial systems - enabling engineers to achieve higher efficiency, smaller footprints, and lower system costs. In addition, the chip integrates a built-in voltage reference and multiple comparators, which can be leveraged for precise voltage monitoring and enhanced system reliability.

Explore the AM1U1412 and its application examples on our Product Page https://www.atlasmagnetics.com/asic
